Table of Contents Toggle OverviewFeaturesSpecificationsFrequency Table (64CH)ApplicationsFAQDatasheet PDF 6.7GHz-7.2GHz 3W FPV VTX Module Overview This module is a high-performance 6.7GHz–7.2GHz 3W video transmitter (VTX) designed for FPV, UAV, and long-range analog video applications. It supports 64 channels and offers up to 3W of RF power output, ensuring strong and reliable video transmission even in challenging environments. With intelligent power control, an integrated cooling fan, and SMA antenna connector, this module delivers excellent signal stability and flexible configuration options. The module has 5 adjustable power levels(25/200/500/1000/3000mW),is equipped with an intelligent audio system for smooth frequency and power adjustment,and features a built-in cooling fan for optimal temperature management.Supporting 64 channels in the 6–7GHz frequency range, The module offers maximum flexibility in signal selection. Its SMA antenna connector ensures a stable connection,and integration with an on-screen menu simplifies setup. 6.7GHz-7.2GHz 3W FPV VTX Module china Features Wide Frequency Range: 6.7GHz–7.2GHz with 64 available channels. Adjustable Power Levels: 25mW / 200mW / 500mW / 1000mW / 3000mW. Smart Cooling System: Built-in fan for temperature control and extended lifespan. Stable Connection: Equipped with SMA antenna connector. Intelligent Audio System: Smooth frequency and power adjustment. Compact Design: Lightweight and small form factor for drone or FPV integration. OSD Configuration: On-screen menu for easy setup and tuning. Specifications Item Description Model FPV-VTX2168 Frequency Range 6.7GHz – 7.2GHz Channel Count 64 Channels Power Output 25mW / 200mW / 500mW / 1000mW / 3000mW Input Voltage 8V – 48V DC Antenna Connector SMA Female Cable Connector JST 6-pin Dimensions 47mm (W) × 36mm (D) Cooling Built-in Fan Kit Contents 1× VTX Module, 1× Cable Frequency Table (64CH) No.\ CH 0 1 2 3 4 5 6 7 1 6110 6130 6150 6170 6190 6210 6230 6250 2 6270 6290 6310 6330 6350 6370 6390 6410 3 6430 6450 6470 6490 6510 6530 6550 6570 4 6590 6610 6630 6650 6670 6690 6710 6730 5 6750 6770 6790 6810 6830 6850 6870 6890 6 6910 6930 6950 6970 6990 7010 7030 7050 7 7070 7090 7110 7130 7150 7170 7190 7210 8 6115 6265 6425 6585 6745 6905 7065 7185 Applications FPV drone and UAV analog video transmission Wireless video monitoring and security systems Industrial inspection and remote camera links Long-range analog broadcast systems Research and development projects requiring stable RF video transmission FAQ Q1: What is the maximum transmission power of the FPV-VTX-2168?A1: It supports up to 3W (3000mW) adjustable output power. Q2: How many frequency channels are available?A2: There are 64 selectable channels from 6.7GHz to 7.2GHz. Q3: Does it include an antenna?A3: The kit includes the VTX module and cable. The antenna is sold separately. Q4: Can it be powered by a drone battery?A4: Yes. It supports a wide voltage range from 8V to 48V, suitable for most drone power systems. Q5: What type of video system is it compatible with?A5: It’s designed for analog FPV systems and supports stable real-time video transmission. Datasheet PDF https://isdb-t.com/wp-content/uploads/2025/10/RFVTX-T67-6.7-7.2G-3W-EN-V1.0.pdf
